Kool Amplification - The hot modded Marvell

The hot modded Marvell

The hot modded Marvell

Contemporary plexi tone from ultra clean to ultra hot. Featuring ultra wide gain range, super tight low-end, fast attack, big fat plexi mids and endless sustain.

Worldwide delivery - 14 days money back guarantee
Free shipping in the EU
This product is customizable

 Ch1: "68 Plexi Clean"

Imagine a super clean version of the orginal 68 plexi with a hint of TwinR. Huge, fat and open 3d tubemagic in action. A perfect platform for all pedals. Dial it all the way up and boost it with a clean boost pedal, and you're in 70's ACDC heaven. Milder setting with a strat and some fuzz or tubescreamer and you'll go from SRV to Hendrix.

Channel 2 "Contemporary Plexi Overdrive"

Technically this is a a '68 Plexi with a ''Jose Arredondo style'' tube driven pre-amp booster integrated in the circuit. The result is a ultra wide gain range, ranging from subtle 70's crunch to comtemporary overdrive. What makes this channel so special is the ultra tightness of the bass, alowing you to cut through any mix, literally endless sustain and gain, while retaining the fattest plexi tone imaginable.

Loud & Louder Attenuator

The foot-switchable 'Loud & Louder Attenuator' alows you to attenuate and boost the overal power of the amp from 20 to 50 Watts. As it is footswitchable you can set ''Loud'' for rythem guitar and ''Louder for solo.

True bypass effects loop (foot-switchable)
The effects loop is buffered by 12AU7 tube. Adding the 12AU7, for several reasons, is not the cheapest solution but the 12AU7 does this job best as it affects the original signal least. The effects loop’s volume knob enables you to amplify, attenuate or balance the signal. Last but not least: You can true-bypass the effects loop with the footswitch! Tech talk: True bypass is achieved by a double relay switch at the front- and back of the loop. When the loop is being bypassed the loop physically disappears from the signal path.
A ''level knob'' is added to level, boost or attenuate the signal.

 Main Features:

  • 2 independent channels
  • Channel 1 = '68 Plexi Clean
  • Channel 2 = Modern Plexi Overdrive
  • Bright switches on both channels
  • Channel switch
  • Loud & Louder Attenuators: from 20 watt  to 50 watt
    (L&L combined with master volumes controls, bedroom levels are attainable with excellent tone and sustain)
  • Ultra wide gain range control on both channels for ultimate gain versatility
  • Channel 1 controls: Gain and Master
  • Channel 2 controls: Gain and Master
  • Shared controls: Middle, Treble, Bass, Presence, Loud, Louder
  • True bypass effects loop with level control
  • Footswitch (channel, effects loop, 2x Loud & Louder attanuator / boost)
  • Outputs 4, 8, 16 Ohm or 2x16, 2x8 Ohm



20 to 50 Watt Specification:

  • Output: 20 to 50 Watts R.M.S. (Loud & Louder)
  • OVERTONES transformers, custom made in BRITAIN
  • 2 x TAD Premium EL34B-STR power tubes
  • 4 x pre-amp tubes:
    3 x 12AX7 JJ
    1 x 12AU7 TAD (effects loop)
  • Outputs 4, 8, 16 Ohm or 2x16, 2x8 Ohm
  • Head weight: approx. 16 kg
  • Handsoldered / handwired in the Netherlands
    by Kool Amplification

Finish & Construction:

  • Handmade A to Z bij Kool Amplification
  • dimensions head: H=25 cm W=51 cm D=25 cm
  • dimensions combo: H=52 cm W=51 cm D=25 cm
  • 13 ply lightplex
  • Kool corner construction
  • Tolex: 'Classic Marvell'
